| Hardware Interface | - 4 x 10/100/1000Base-Tx LAN Switch, RJ-45
- 1 x 10/100/1000 WAN Port, RJ-45, 1 x 10/100/1000 WAN Port
- 3 x Detachable Antennas
- 2 x USB Host 2.0
- 1 x Factory Reset Button
- 1 x Wireless on/off/WPS Button
| | Temperature | Operating : 0°C ~ 45°C
Storage : -25°C ~ 70°C | | Humidity | 10% ~ 90% ( non-condensing ) | | Power Adapter | DC12V | | Max. Power | 10 watt | | Dimension | L216.4 * W147.8 * H53.5 ( mm ) | IP Version Support Hardware NAT
Switch - 4 Gigabit LAN Ports
- Port-based VLAN (LAN)
- Layer-2 (802.1p) QoS
- 802.1q Bridge / Multi-VLAN (WAN)
- IGMP Snooping
- Bind IP to MAC Address
WAN Protocol - DHCP Client
- Static IP
- PPPoE
- PPTP
- L2TP
Wireless AP - IEEE802.11ac Compliant
- 64 / 128-bit WEP
- WPA / WPA2
- Hidden SSID
- MAC Address Access Control
- WPS
- Wireless Client List
- Multiple SSID
- WDS
Firewall - DMZ Host, Open Port, Port-redirection
- ACL (Access Control List)
- MAC Address Filter
- SPI (Stateful Packet Inspection)
- DoS Prevention
- IP Address Anti-spoofing
- Web Syslog
- Logging via Syslog
- E-mail / SMS Alert
Network Feature - DHCP Server
- Dynamic DNS
- NTP Client
- UPnP
- IGMP Proxy V2
- DNS Cache / Proxy
- Static / Policy Routing
- WOL (Wake on LAN)
Bandwidth Management - Layer 2/3 QoS by Ethernet Type, VLAN ID, TCP / UDP Port, DSCP, ToS, Tag Priority
- QCL (QoS Control List)
- Bandwidth / Session Limitation
CSM (Content Security Management) - APP Enforcement
- URL Content Filter
- Including Capability of Blocking Unwanted HTTPS Web Site (Such as Social Network, Facebook) *
- GlobalView Web Content Filter (Powered by
 , optional procurement of yearly license) Network Management - Web Portal Log-in for LAN and WLAN Users Including Notifications on Bulletin Board to Remind the Network Users *
- Web-based User Interface (HTTP / HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface, Telnet / SSH)
- Configuration Backup / Restore
- Built-in Diagnostic Function
- Firmware Upgrade via WUI
- 2-level User Management (admin / user)
- Administration Access Control
- Logging via Syslog
- Management Session Time out
- SNMP Management MIB-II
- TR-069
VPN - 2 VPN Tunnels
- PPTP / IPSec LAN to LAN , L2TP over IPSec and PPTP Remote Dial in
- Encryption : 3DES, AES
- Authentication : MD5, SHA-1
- IKE Authentication : Pre-shared Key
- DPD
- VPN Pass-through
- PPTP MPPE
- X.509 Certificate *
USB Port - Act as Printer Server by Connection to USB Printer
- Act as NAS
- Add a USB Memory Sticks or USB Hard Drives for Shared Multimedia Storage / Access
- The Above Mentioned NAS / FTP
|
