| Hardware Interface | - 1x 100/1000Mbps Port, SFP Slot (WAN1)
1 x 10/100/1000Base-TX, RJ-45 (WAN2) - 4 x 10/100/1000Base-TX LAN, RJ-45
Configurable Physical DMZ on Port1 - 2 x Detachable Antennas
- 2 x USB Host 2.0
- 1 x Factory Reset Button
- 1 x Wireless On/Off/ WPS Button
| | Temperature | Operating : 0°C ~ 45°C
Storage : -25°C ~ 70°C | | Humidity | 10% ~ 90% ( non-condensing ) | | Power | DC 12V / 1.5A | | Power Consumption | 10 watt | | Dimension | L240.96 * W165.07 * H43.96 ( mm ) | WAN Feature - IPv4 Ethernet WAN
- DHCP Client
- Static IP
- PPPoE
- PPTP
- L2TP
- 802.1p/q Multi-VLAN Tagging
- IPv6 Ethernet WAN
- Tunnel Mode:
- Dual Stack:
- DHCPv6 Client
- Static IPv6
- USB WAN
- Outbound Policy-based Load-balance
- WAN Connection Failover
- WAN Budgets*
- 50,000 NAT Sessions
Network Feature - DHCP Client/Relay/Server
- IGMP Snooping/Proxy Version 2 and Version 3
- Dynamic DNS
- NTP Client
- Call Scheduling
- RADIUS Client
- DNS Cache/Proxy
- UPnP 30 sessions
- Multiple Subnets
- Port-based/Tag-based VLAN (802.1q)
- Layer-2 QoS (802.1p)
- Routing Protocol:
- Route Policy
VPN - Up to 50 VPN Tunnels
- Protocol : PPTP, IPsec, L2TP, L2TP over IPsec
- Encryption : MPPE and Hardware-based AES/DES/3DES
- Authentication : MD5, SHA-1
- IKE Authentication : Pre-shared Key and Digital Signature (X.509)
- LAN-to-LAN, Teleworker-to-LAN
- DHCP over IPsec
- IPsec NAT-traversal (NAT-T)
- Dead Peer Detection (DPD)
- VPN Pass-through
- VPN Wizard
- mOTP
- SSL VPN (Up to 25 Tunnels)
- VPN Trunk (Load Balance/Backup)
Firewall - Multi-NAT, DMZ Host, Port-redirection and Open Port
- Object-based Firewall, Object IPv6, Group IPv6
- MAC Address Filter
- SPI (Stateful Packet Inspection) (Flow Track)
- DoS Prevention
- IP Address Anti-spoofing
- E-mail Alert and Logging via Syslog
- Bind IP to MAC Address
- Time Schedule Control
- User Management
USB - 3.5G (HSDPA)/4G (LTE) as WAN
- Printer Sharing
- File System :*
- Support FAT32 File System *
- Support FTP Function for File Sharing *
- Support Samba for File Sharing*
Bandwidth Management - QoS :
- Class-based Bandwidth Guarantee by User-defined Traffic Categories
- Guarantee Bandwidth for VoIP
- DiffServ Code Point Classifying
- 4-level Priority for Each Direction (Inbound/Outbound)
- Bandwidth Borrowed
- Session Limitation
- Default & Specific Limitation
- Bandwidth Limitation
- Default & Specific Limitation
- Auto Adjustment by Exceeding Session/Available Bandwidth
- TOS/DSCP QoS Mapping
Network Management - Web-Based User Interface (HTTP/HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface, Telnet/SSH)
- Administration Access Control
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via TFTP/FTP/HTTP/TR-069
- Logging via Syslog
- SNMP Management MIB-II (v2/v3)
- Management Session Time Out
- 2-level management (Admin/User Mode)
- TR-069
- TR-104
- LAN Port Monitoring
- Support Smart Monitor (Up to 50 nodes)
- Central AP Management (Up to 20 APs)
Content Security Management - IM/P2P Applications
- GlobalView Web Content Filter (Powered by CYREN-90) *
- URL Content Filter
- URL Keyword Blocking (Whitelist and Blacklist)
- Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking
- Excepting Subnets
Wireless AP - IEEE802.11n Compliant (2.4GHz)
- Wireless Client List
- Wireless LAN Isolation
- 64/128-bit WEP
- WPA/WPA2
- Hidden SSID
- WPS
- MAC Address Access Control
- Access Point Discovery
- WDS (Wireless Distribution System)
- 802.1x Authentication
- Multiple SSID
- Wireless Rate-control
- IEEE802.11e: WMM (Wi-Fi Multimedia)
- SSID VLAN Grouping with LAN Port*
|
