2*GigaWAN, 5*GigaLAN, 2*USB(3G/4G, FTP/Samba, Printer, temperature sensor), VoIP (2*FXS, 1*Line, SIP Accounts(12), ZRTP+SRTP), Возможность использовать WiFi Wireless 2.4G в качестве WAN2, 50 VPN, 25 SSL VPN, SSL VPN (LAN to LAN), VPN Backup, VPN Load Balance, Central VPN Management (8/16), User Management, Firewall, QoS, Multi-LAN (5+DMZ+IP Routed Subnet), Load-Balance/Route Policy (50), WAN Budget, High Availability, Internal RADIUS, 802.1q (WAN, LAN), CSM, TR-069, WiFi 802.11n 300Mb Dual Band 4 SSID 2,4GHz+ 802.11ac 1300Mb 4 SSID 5GHz, Wireless Station Control, Web Portal (Advertisement), 3*Ant R-SMA, Central AP Management (20), Switch Management, IPTV, SMS/Mail Alert Service, IPv6, SmartMonitor 50, Dashboard 1. WAN Protocol - Giga Ethernet (WAN1 & WAN2)
- DHCP Client
- Static IP
- PPPoE
- PPTP/L2TP (WAN-2 only)
- PPPoA (ADSL2 only)
- 802.1q Multi-VLAN Tagging
- USB (WAN3 & WAN4)
- IPv6
| 2. USB - 3.5G/4G-LTE as Primary or Backup WAN
| 3. VPN - Up to 50 VPN Tunnels
- Protocol : PPTP, IPsec, L2TP, L2TP over IPsec
- Encryption : MPPE and Hardware-based AES/DES/3DES
- Authentication : MD5, SHA-1
- IKE Authentication : Pre-shared Key and Digital Signature (X.509)
- LAN-to-LAN, Teleworker-to-LAN
- DHCP over IPsec
- IPsec NAT-traversal (NAT-T)
- Dead Peer Detection (DPD)
- VPN Pass-through
- VPN Wizard
- mOTP
- SSL VPN: 16 Tunnels
- VPN Trunk (Load Balance/Backup)
| 4. Multi-WAN - Load-Balance/Route Policy
(The Gigabit Ethernet interface and USB mobile can be used either for WAN-backup or load balancing.) - WAN Connection Failover
| 5. CSM (Content Security Management) - IM/P2P Application
- GlobalView Web Content Filter (Powered by
 ) - URL Content Filter :
- URL Keyword Blocking (Whitelist and Blacklist)
- Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking
- Excepting Subnets
| 6. Bandwidth Management - QoS
- Bndwidth/Session Limitation
- Layer-2 (802.1p) and Layer-3 (TOS/DSCP) QoS Mapping
| 7. Network Feature - Packet Forwarding Acceleration*
- DHCP Client/Relay/Server
- IGMP Snooping/Proxy V2 and V3
- Triple-Play Application
- Dynamic DNS
- NTP Client
- Call Scheduling
- RADIUS Client
- DNS Cache/Proxy and LAN DNS
- UPnP 30 sessions
- Multiple Subnets
- Port-based/Tag-based VLAN (802.1q)
- Routing Protocol:
| 8. Network Management - Web-based User Interface (HTTP/HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface, Telnet/SSH)
- Administration Access Control
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via TFTP/FTP/HTTP/TR-069
- Logging via Syslog
- SNMP Management MIB-II
- Management Session Time Out
- 2-level Management (Admin/User Mode)
- TR-069
- TR-104
- LAN Port Monitoring
- Support Smart Monitor (50 clients)
- Central AP Management (20 nodes)
- Central VPN Management (Up to 8 Remote Routers)
| 9. Firewall - Multi-NAT, DMZ Host, Port-redirection and Open Port
- Object-based Firewall, Object IPv6, Group IPv6
- MAC Address Filter
- SPI (Stateful Packet Inspection) (Flow Track)
- DoS/DDoS Prevention
- IP Address Anti-spoofing
- E-mail Alert and Logging via Syslog
- Bind IP to MAC Address
- Time Schedule Control
- User Management
10. Wireless AP - 802.11ac Wireless Access Point (300Mbps @ 2.4GHz and 1300 Mbps @5GHz 11ac)
- Wireless Client List
- Wireless LAN Isolation
- 64/128-bit WEP
- WPA/WPA2
- Wireless Wizard
- Hidden SSID
- WPS
- MAC Address Access Control
- Access Point Discovery
- WDS (Wireless Distribution System)
- 802.1x Authentication
- Multiple SSID
- Wireless Rate-control
- IEEE802.11e: WMM (Wi-Fi Multimedia)
- SSID VLAN Grouping with LAN Port (Port-based VLAN)
11. VoIP - Protocol: SIP, RTP/RTCP
- 12 SIP Registrars
- G.168 Line Echo-cancellation
- Jitter Buffer
- Voice codec:
- G.711
- G.723.1
- G.726
- G.729 A/B
- VAD/CNG
- DTMF Tone :
- Inband
- Outband (RFC-2833)
- SIP Info
- FAX/Modem Support :
- Tone Detection
- G.711 Pass-through
- T.38.
- Supplemental Services :
- Call Hold/Retrieve/Waiting
- Call Waiting with Caller ID*
- Call Transfer
- Call Forwarding (Always, Busy and No Answer)
- Call Barring (Incoming/Outgoing)
- DND (Do Not Disturb)
- MWI (Message Waiting Indicator) (RFC-3842)
- Hotline
- Secure Phone (ZRTP + SRTP)
- PSTN Loop-through When Power Failure
- Dial Plan :
- Phone Book
- Digit Map
- Call Barring
- Regional
| Hardware Interface | LAN | 5 x 10/100/1000Base-Tx LAN Switch, RJ-45 | | WAN | 2 x 10/100/1000Base-Tx, RJ-45 | | USB | 2 x USB Host 2.0 | | 3 x Detachable Antennas | | 2 x FXS and #1 x Life Line Port, RJ11 | | 1 x Factory Reset Button | | 1 x Wireless On/ Off/ WPS Button | | Temperature | Operating : 0°C ~ 45°C | | Storage : -25°C ~ 70°C | | Humidity | 10% ~ 90% (non-condensing) | | Max. Power | 24 Watt | | Dimension | L241 * W165 * H44 (mm) | | Power | DC 12V @ 1.5A ~ 2A |
|
