Hardware |
Interface |
-
2 x GbE WAN port
-
1 x SIM card slot
(with optional fixed cover)
-
4 x GbE LAN port
-
1 x USB 2.0 port
-
Factory Reset Button
-
Power On/Off Switch
|
Power |
-
DC 12V @1.5~2A
-
Max. Power Consumption: 24 watts
|
Temperature |
-
Operating: 0°C ~ 45°C
-
Storage: -25°C ~ 70°C
|
Humidity |
-
Operating: 10% ~ 90%
(non-condensing)
|
Dimension (mm) |
|
WAN |
LTE |
-
LTE Category 4
-
Maximum Data Rate: 150 Mbps Download, 50 Mbps Upload
-
LTE FDD Band: 1(2100MHz), 3(1800MHz), 7(2600MHz), 8(900MHz), 20(800MHz)
-
LTE TDD Band: 38(2600MHz), 40(2300MHz)
-
WCDMA (3G) Band: 1, 8
-
GSM/GPRS/EDGE Band: 900, 1800 MHz
-
Automatic Fallback to 3G/2G
|
Ethernet Connection (IPv4) |
-
PPPoE Client
-
DHCP Client
-
Static IP
-
PPTP/L2TP
-
802.1Q VLAN Tagging
-
Triple-Play Applications
|
Ethernet Connection (IPv6) |
-
PPP
-
DHCPv6 Client
-
Static IPv6
-
TSPC
-
AICCU (AYIYA/Heartbeat)
-
6rd
-
6in4 Static Tunnel
|
Load Balancing |
-
IP-based Load Balancing
-
Session-based Load Balancing
-
WAN Data Budget
|
Failover |
-
Failover by Link Failure
-
Failover by Traffic Threshold
|
Connectivity Detection |
|
High Availability |
-
Method: Active-Standby /Hot-Standby
-
Automatic Configuration Sync
-
WCF License Key Sharing
|
LAN Managment |
VLAN |
-
Up to 16 VLAN
-
802.1Q Tag-based VLAN
-
Port-based VLAN
|
DHCP Server |
-
Up to 8 IP Subnet
-
Supports up to 1022 IP addresses on Subnet 1-3
-
Bind-IP-to-MAC
-
Custom DHCP Option
|
Security |
-
Wired 802.1x authentication
|
DNS Control |
-
Local Name Server
-
Conditional DNS Forwarding
|
Hotspot Portal |
-
Authentication by Click-Through, Social Login, and SMS PIN
-
Custom Portal Page
-
URL Redirection
-
Walled-Garden
-
User Info Collection
|
Routing |
Static Route |
-
40 IPv4 Static Routing Rules
-
40 IPv6 Static Routing Rules
-
Inter-VLAN Routing
|
Dynamic Routing |
|
Policy-Based Routing |
-
50 Route Policy
-
Criteria: Protocol, Source IP, Destination IP, Destination Domain Name, Destination Country, Destination Port
-
Failover options
|
VPN |
Performance |
-
Up to 50 concurrent tunnels
-
Up to 25 concurrent SSL VPN
|
Protocols |
-
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2
-
LAN-to-LAN VPN
-
Teleworker-to-LAN VPN
|
Encryption |
-
MPPE 40/128 bit
-
Hardware-based AES/DES/3DES
|
Authentication |
-
PAP, CHAP, MS-CHAP, MS-CHAPv2
-
MD5, SHA-1
-
Pre-Shared Key, Digital Signature (X.509)
-
mOTP
|
Advanced |
-
Hub-and-Spoke Topology support
-
DHCP over IPsec
-
VPN Redundancy for Load Balancing or Failover
-
NAT-Traversal (NAT-T)
-
Dead Peer Detection (DPD)
-
Single-Armed VPN
|
Firewall |
NAT |
-
One-to-One Port Redirection
-
Range-to-Range Port Redirection
-
Open Ports
-
Port Triggering
-
DMZ Host
-
ALG: SIP, RTSP, FTP, TFTP, H.323
-
VPN Pass-Through: PPTP, L2TP, IPsec
-
UPnP
|
Firewall Filter |
-
IP-based Firewall Policy
-
User-based Firewall Policy
-
Object-based Configuration
-
Schedule Enable/Disable
|
Content Filtering |
-
URL Keyword Filtering
-
Category Filtering (subscription required)
-
DNS Keyword Filtering
-
Web Features Filtering
|
Attack Protection |
|
Bandwidth Management |
Bandwidth Management |
-
Session Limit
-
Bandwidth Limit
-
IP-Based Policy
-
Scheduled Enable/Disable
|
Quality of Service |
-
Layer 3 QoS (TOS/DSCP)
-
Layer 2 QoS (802.1p)
-
4-Level Priority with user-defined classification
-
Bandwidth Borrowing
-
Guaranteed bandwidth for VoIP traffic
-
APP QoS
|
Cellular Services |
Cellular Services |
-
Sending & Receiving SMS
-
SMS initiated Router Reboot
-
Router status reporting via SMS
-
SMS Quota Limit
|
Network Features |
Network Features |
-
Dynamic DNS
-
DNS Security (DNSSEC)
-
Bonjour
-
IGMP Proxy
-
IGMP Snooping
-
SMB File Sharing
|
User Authentication |
-
Local User Database
-
RADIUS Server
-
Active Directory/LDAP
-
TACACS+
-
Internal RADIUS Server
|
Wireless LAN (Ln/Lac model) |
Standards |
-
802.11 b/g/n (2.4G)
-
802.11a/n/ac/ac Wave-2 (5G)
-
4x4 MU-MIMO (5G)
-
TX Beam Forming (5G)
|
Frequency (USA) |
-
2.412 ~ 2.462 GHz (2.4G)
-
5.150 ~ 5.250 GHz (5G)
-
5.725 ~ 5.825 GHz (5G)
|
Frequency (Europe ETSI) |
-
2.412 ~ 2.472 GHz (2.4G)
-
5.150 ~ 5.250 GHz (5G)
-
5.470 ~ 5.725 GHz (5G)
|
SSID |
-
Up to 4 SSID per radio
-
SSID-based 802.1Q VLAN
|
Radio Management |
-
Auto Channel Selection
-
Auto Channel Width (2.4G)
-
Wi-Fi Scheduling
|
Security |
-
WEP, WEP-802.1x, WPA-PSK, WPA-802.1x, WPA2-PSK, WPA2-802.1x
-
Hidden SSID
-
Client Isolation
-
Access Control per SSID
-
WPS
|
Advanced |
-
Rate Control per SSID
-
AirTime Fairness
-
Band Steering
(Lac model)
-
WMM
|
WDS |
|
Management |
Configuration |
-
Web Interface: HTTP, HTTPS
-
Command-Line Interface: Telnet, SSH
-
TR-069 via VigorACS
-
Config File Export & Import
-
Compliant with the config file exported from Vigor2860
|
F/W Upgrade |
|
Admin Access Control |
-
2-level Administration Privilege
-
Access from the Internet
-
Access List
-
Brute Force Protection
|
Monitoring |
-
Dashboard
-
Syslog
-
SMS/E-mail Alert
-
TR-069 via VigorACS
-
SNMP v2c, v3
|
Central Management |
-
Wireless Controller for up to 20 VigorAP
-
10 Vigor Switch
-
8 Vigor Router (CVM Feature)
|
