| Hardware Interface | - 1 x ADSL2/VDSL2 Port (WAN-1), RJ-11 for Annex A/RJ-45 for Annex B
- 1 x 1000Base-TX, RJ-45 (WAN-2)
- 6 x 10/100/1000Base-TX LAN, RJ-45
- 3 x Detachable Antennas (ac Model)
- 1 x FXS and 2 x FXO, RJ11
- 2 x USB Host 2.0
- 1 x Factory Reset Button
- 1 x Wireless On/Off/ WPS Button (ac Model)
| | Temperature | Operating : 0°C ~ 45°C
Storage : -25°C ~ 70°C | | Humidity | 10% ~ 90% ( non-condensing ) | | Power Adapter | DC12V @1.5A~2A | | Power Consumption | 24 watt | | Dimension | L241 * W165 * H44 ( mm ) | IP PBX Features - 50 account (extensions)
- 12 SIP Trunk
- Registration and authentication
- BLF (Busy-lamp Field)
- Hunting Group
- IVR
- Calendar
- Dial Plan (Digit Map)
- Session Monitor
- Call Detail Records
- DID
- Extension Privilege Assign
- PIN Code Control
- Call Barring, Call Park , Call Pickup
- In/Outbond Call Through FXO Interface
- In/Outbond Call Through External ATA Gateway Interface (Custom Trunks x8)
- User-defined Prompts / Automated Attendant
- MWI (Message Waiting Indicator)
- Voice Message to Email
- Music on Hold
- Internet Extension White List / Auto Blocking (Password Attacking)
- Virtual FAX
VDSL2/ADSL2/2+ modem - ITU-T G.993.2 (VDSL2)
- ITU-T G.992.1/3/5 (ADSL1/2/2+) Annex A & Annex B
- DSL Forum Performance Specification: ADSL TR-048/67, TR-100; VDSL: WT-114
- Erasure Decoding, Increased Interleaver Depth and Re-transmission
- EFM (IEEE 802.3 ah)
- VDSL2 Profile: up to 30a
WAN Protocol - DSL (WAN-1)/Giga Ethernet (WAN-2)
- DHCP Client
- Static IP
- PPPoE
- PPTP/L2TP (WAN-2 only)
- PPPoA (ADSL2 only)
- 802.1q Multi-VLAN Tagging
- USB (WAN 3/WAN 4)
- IPv6
- Tunnel Mode: TSPC, AICCU, 6rd, Static 6in4
- Dual Stack: PPP, DHCPv6 Client, Static IPv6
USB - 3G/LTE (HSDPA) as WAN 3/WAN 4
- Printer Sharing
- File System
- Support FAT32 File System
- Support FTP Function for File Sharing
- Support Samba for File Sharing
- LTE USB mobile Support List Please Contact
VPN - Up to 32 VPN Tunnels
- Protocol : PPTP, IPsec, L2TP, L2TP over IPsec
- Encryption : MPPE and Hardware-based AES/DES/3DES
- Authentication : MD5, SHA-1
- IKE Authentication : Pre-shared Key and Digital Signature (X.509)
- LAN-to-LAN, Teleworker-to-LAN
- DHCP over IPsec
- IPsec NAT-traversal (NAT-T)
- Dead Peer Detection (DPD)
- VPN Pass-through
- VPN Wizard
- mOTP
- SSL VPN: 16 Tunnels
- VPN Trunk (Load Balance/Backup)
Multi-WAN - Load-Balance/Route Policy
(The VDSL2/ADSL2+ interface, Gigabit Ethernet interface, LTE modem and USB mobile can be used either for WAN-backup or load balancing.) - WAN Connection Failover
CSM (Content Security Management) - IM/P2P Application
- GlobalView Web Content Filter (Powered by
 ) - URL Content Filter :URL Keyword Blocking (Whitelist and Blacklist)
- Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking
- Excepting Subnets
Bandwidth Management - QoS
- Guarantee Bandwidth for VoIP
- Class-based Bandwidth Guarantee by User-defined Traffic Categories
- DiffServ Code Point Classifying
- 4-level Priority for Each Direction (Inbound/Outbound)
- Bandwidth Borrowed
- Bndwidth/Session Limitation
- Layer-2 (802.1p) and Layer-3 (TOS/DSCP) QoS Mapping
Network Feature - Packet Forwarding Acceleration*
- DHCP Client/Relay/Server
- IGMP Snooping/Proxy V2 and V3
- Triple-Play Application
- Dynamic DNS
- NTP Client
- Call Scheduling
- RADIUS Client
- DNS Cache/Proxy and LAN DNS
- UPnP 30 sessions
- Multiple Subnets
- Port-based/Tag-based VLAN (802.1q)
- Routing Protocol :
Network Management - Web-based User Interface (HTTP/HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface, Telnet/SSH)
- Administration Access Control
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via TFTP/FTP/HTTP/TR-069
- Logging via Syslog
- SNMP Management MIB-II
- Management Session Time Out
- 2-level Management (Admin/User Mode)
- TR-069
- TR-104
- LAN Port Monitoring
- Support Smart Monitor (50-nodes)
Firewall - Multi-NAT, DMZ Host, Port-redirection and Open Port
- Object-based Firewall, Object IPv6, Group IPv6
- MAC Address Filter
- SPI (Stateful Packet Inspection) (Flow Track)
- DoS Prevention
- IP Address Anti-spoofing
- E-mail Alert and Logging via Syslog
- Bind IP to MAC Address
- Time Schedule Control
- User Management
Wireless AP - 802.11ac WLAN
- Wireless Client List
- Wireless LAN Isolation
- 64/128-bit WEP
- WPA/WPA2
- Wireless Wizard
- Hidden SSID
- WPS
- MAC Address Access Control
- Access Point Discovery
- WDS (Wireless Distribution System)
- 802.1x Authentication
- Multiple SSID
- Wireless Rate-control
- IEEE802.11e: WMM (Wi-Fi Multimedia)
- SSID VLAN Grouping with LAN Port (Port-based VLAN)
|
