System |
|
Standard |
-
802.3 10Base-T
-
802.3u 100Base-T
-
802.3ab 1000Base-TX
-
802.3x Flow Control
-
802.3 Auto-Negotiation
-
802.3at PoE+
-
802.3af PoE
|
|
Performance |
-
128 KB Buffer Size
-
16 Gbps switching capacity
-
11.9 Mpps forwarding rate (64 bytes)
-
8k MAC Address
-
Up to 9KB jumbo frame
|
|
Hardware |
|
Ports |
-
8 x 10/100/1000Base-T, RJ-45
|
|
Power |
-
Input: 100~240V/AC; 50~60Hz
-
Max. Power Consumption: 150 watts
|
|
Power over Ethernet (PoE) |
|
Standard |
-
802.3af (PoE)
-
802.3at (PoE+)
|
|
Power Budget |
|
|
Physical Specification |
Dimension
(L x W x H) |
-
262mm x 184mm x 41mm
(10.3" x 7.2" x 1.6")
|
|
Weight |
|
|
Environmental Requirement |
|
Temperature |
-
Operating: 0°C ~ 40°C
-
Storage: -20°C ~ 90°C
|
|
Humidity |
-
Operating: 10% ~ 90%
(non-condensing)
|
